1 Wire Pi
1 Wire Pi and 1 Wire Pi Plus Tutorials
The 1 Wire Pi Plus and 1 Wire Pi Zero from AB Electronics UK are communication boards supporting the 1-Wire® protocol designed for use on the Raspberry Pi and other compatible single-board computers.
The 1-Wire® port is based around a DS2482-100 I2C to 1-Wire® bridge device. The DS2482-100 provides bi-directional protocol conversion between the I2C port on the Raspberry Pi and any attached 1-Wire® devices.
This knowledge base section contains articles and tutorials on the 1 Wire Pi Plus and 1 Wire Pi Zero, showing how to use the development board with various devices.
Find out more about the 1 Wire Pi Plus and 1 Wire Pi Zero.
